DS-KH8380-WTE1/Flush

8 Series Indoor Station

DS-KH8380-WTE1/Flush
DS-KH8380-WTE1/Flush 1
DS-KH8380-WTE1/Flush 2
DS-KH8380-WTE1/Flush 3

Product Features

1

7-inch TFT touchscreen with 1024 × 600 resolution

2

Remote access via Hik-Connect app: receive calls, unlock doors, view live feed

3

IEEE802.3at PoE for device and lock power

4

Supports up to 16 linked indoor extensions

5

Integrated elevator access control

6

Surface and flush mounting options

7

Multiple interfaces: alarm input, RS-485, relays, TF card slot

Request Information

Technical Specifications

Operation systemEmbedded Linux operation system
ROM32 MB
RAM128 MB
ProcessorEmbedded high performance processor
Screen size7-inch
Operation methodCapacitive touch screen
TypeColorful TFT
Resolution1024×600
Lens/
Resolution/
FOV/
Wide dynamic range WDR/
Video compression standardH.265；H.264
Focal length/
Audio input1 built-in omnidirectional microphone
Audio compression standardG.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
Audio output1 built-in loudspeaker
Audio compression bitrate16/32/64 Kps
Audio qualityNoise suppression and echo cancellation
Volume adjustmentAdjustable
