networkcamera • NEW
DS-2CD2347G2-L(U)
4 MP ColorVu Fixed Turret Network Camera
-1.Qa6_JlZq.png)
-2.C77Mj9MN.png)
-3.DRT70M9R.png)
-4.BgS_UjOx.png)
Product Features
1
4 MP high-resolution imaging
2
H.265+ compression for efficient storage
3
130 dB WDR for clear images in backlit conditions
4
Built-in microphone for real-time audio security
5
Deep learning for human and vehicle classification
6
24/7 colorful imaging
7
IP67 water and dust resistance
Technical Specifications
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max Resolution | 2688 × 1520 |
| Min Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Focal Length FOV | 2.8 mm: Horizontal FOV 112°, Vertical FOV 61°, Diagonal FOV 134° 4 mm: Horizontal FOV 95°, Vertical FOV 51°, Diagonal FOV 115° 6 mm: Horizontal FOV 58°, Vertical FOV 31°, Diagonal FOV 69° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 2.5 m to ∞ 4 mm: 3.5 m to ∞ 6 mm: 7.5 m to ∞ |
| Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Video Compression | Main Stream: H.265/H.264/H.265+/H.264+ Sub Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H264 Type | Baseline Profile/Main Profile/High Profile |
| H265 Type | Main Profile |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding | H.264 and H.265 encoding |
| Region of Interest | 1 fixed region for main stream and sub-stream |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
