networkcamera • NEW
DS-2CD1743G0-I(Z)
4 MP Varifocal Dome Camera
-1.B_Se5yqm.webp)
-2.B_koYyOY.webp)
-3.DB1VGXEo.webp)
Product Features
1
4 MP high-quality imaging for clear surveillance
2
120 dB WDR for strong backlight performance
3
2.8–12 mm motorized varifocal lens for flexible monitoring
4
H.265+ compression for efficient storage and bandwidth
5
EXIR 2.0: advanced infrared tech with long IR range
6
IP67 water/dust resistance and IK10 vandal protection
Technical Specifications
| Image Sensor | 1/3" Progressive Scan CMOS |
| Max Resolution | 2560 × 1440 |
| Min Illumination | Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Wide Dynamic Range | 120 dB |
| Day Night | IR Cut Filter |
| Angle Adjustment | Pan: 0° to 355°, Tilt: 0° to 70°, Rotation: 0° to 355° |
| Lens Type | Varifocal Lens, motoried lens, 2.8 to 12 mm |
| Focal Length FOV | 2.8 to 12 mm: Horizontal FOV 102° to 31°, Vertical FOV 54° to 17°, Diagonal FOV 123° to 35° |
| Lens Mount | Ø14 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Main Stream | 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720) |
| Sub Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub Stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H264 Type | Baseline Profile/Main Profile/High Profile |
| H265 Type | Main Profile |
| Region of Interest | 1 fixed region for main stream |
| Audio Compression | -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | -S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate | -S: 8 kHz/16 kHz |
| Environment Noise Filtering | -S: Yes |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface, ISAPI |
| User Host | Up to 32 users. 3 levels: administrator, operator and user |
| Network Storage | MicroSD/SDHC/SDXC card (256 GB) local storage |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Plug-in required live view: IE 10+; Plug-in free live view: Chrome 57.0+, Firefox 52.0+; Local service: Chrome 57.0+, Firefox 52.0+ |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day Night Switch | Auto, Schedule, Day, Night |
| Image Enhancement | BLC, 3D DNR |
| Power | 12 VDC ± 25%, 0.8 A, max. 10 W, Ø5.5 mm coaxial power plug; PoE: 802.3af, Class 3, 36 V to 57 V, 0.32 A to 0.2 A, max. 11.5 W |
| Camera Material | Metal |
| Camera Dimension | Ø141 mm × 99.9 mm (Ø5.6" × 3.9") |
| Package Dimension | 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1") |
| Camera Weight | Approx. 820 g (1.8 lb.) |
| With Package Weight | Approx. 1200 g (2.6 lb.) |
| Storage Conditions | -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Language | English, Ukrainian |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
