DS-E04HGHI-XD

4K ColorVu PoC Fixed Turret Camera

DS-E04HGHI-XD
DS-E04HGHI-XD 1
DS-E04HGHI-XD 2
DS-E04HGHI-XD 3
DS-E04HGHI-XD 4

Product Features

1

4-channel DVR with 1080p Lite@30fps encoding capability

2

Powered by M-SATA eSSD technology for enhanced performance

3

Deep learning-based human and vehicle classification with Motion Detection 2.0

4

Scene-adaptive bitrate control for efficient video compression

5

Supports audio transmission via coaxial cable

6

Low power consumption for energy-efficient operation

Request Information

Technical Specifications

IP Video Input
Channels: 1-ch
Resolution: Up to 1080p
Support: H.265+/H.265 IP cameras
Analog Video Input
Channels: 4-ch
Interface: BNC (1.0 Vp-p, 75 Ω), supports coaxitron connection
HDTVI Input
1080p25:
1080p30:
720p25:
720p30:
AHD Input
1080p25:
1080p30:
720p25:
720p30:
HDCVI Input
1080p25:
1080p30:
720p25:
720p30:
CVBS InputSupport
HDMI Output1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
VGA Output1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
Video Output ModeHDMI/VGA simultaneous output
Audio Input4-ch via coaxial cable
Audio Output1-ch via HDMI
Synchronous Playback4-ch
Video CompressionH.265 Pro/H.265
Encoding Resolution
1080p Lite:
720p:
720p Lite:
WD1:
4CIF:
CIF:
QVGA:
Frame Rate
Main Stream: 1080p Lite/720p/720p Lite/WD1/4CIF@25 fps (P)/30 fps (N)
Default: 1080p Lite/720p is 15 fps by default
Sub Stream: 4CIF@15 fps; CIF/QVGA@25 fps (P)/30 fps (N)
Video BitrateScene-adaptive bitrate control to ensure recording stability
Stream TypeVideo, Video & Audio (Audio recording must be manually enabled)
Audio CompressionG.711u
Audio Bitrate64 Kbps
Total Bandwidth64 Mbps
Incoming Bandwidth4 Mbps
Remote Connection32
Network Protocol
TCP/IP:
DHCP:
Hik-Connect:
DNS:
DDNS:
NTP:
SADP:
SMTP:
NFS:
UPnP™:
HTTPS:
Network Interface1 × RJ45 10/100 Mbps self-adaptive Ethernet interface
Power Supply12 VDC, 1 A
Consumption≤ 5.4 W (with eSSD)
Working Temperature-10 °C to 45 °C (14 °F to +113 °F)
Working Humidity10% to 90%
Dimension152 × 113 × 46 mm (6.0 × 4.4 × 1.8 inch)
Weight≤ 0.5 kg (with eSSD, 1.1 lb.)
